Technical
data |
|
|
Self centering
chuck opening |
10" - 18" (>
<) / 13" - 21" (< >) |
|
Bead breaking
power (blade) |
15.500 N (10
BAR) |
|
Bead breaking
power (cylinder) |
32.200 N (10
BAR) |
|
Bead breaking
blade opening |
320 mm.
|
|
Max. wheel
diameter |
1010 mm.
|
|
Wheel width
|
3" - 12"
|
|
Working pressure |
10 BAR
|
|
Max. self
centering torque |
120 Kgm
|
|
Noise level when
running |
< 70 dB (A)
|
|
Motor
|
0.55 Kw - 3 Ph
- 400 V - 50 Hz |
|
Weight |
175 Kg. (FS) - 165 Kg.
|
|
Supplied
accessories |
|
|
Tire lever |
|
|
Set of 4 plastic
jaw pads |
|
|
Filter pressure
reducer unit
Cover for tire lever
Plastic cover for
blade
|
|
|
Optional
accessories |
|
|
M 318 |
|
|
Tire inflating
gun, EEC homol. |
cod. 801.276833 |
|
Double scale tyre
inflating gun |
cod. 801.271621 |
|
M 318 FS - M 318 |
|
|
Set of 4
motorcycle attachments |
cod. 8-1110.00.36 |
Special bead
breaker blade for bikes
Kit of 6 covers
for tire levers
|
cod. 801.260402
cod. 801.246241 |
|
Kit of 6 plastic
covers for blade |
cod. 801.258383 |
Horizontal
positioning of the tool is obtained by means of a
threaded hand wheel. Operating on various wheels of the same
dimensions means that tool maintains position originally
regulated for. The single action lever locks the shaft
vertically, causing at the same time the movement upwards of
the peak. At the base of the post, a thermoformed carter
provides a housing for 1 Kg standard lube can as well as a
large housing for small pieces.
