Service more vehicles and make more money with
CL10series automotive lifts. Versymmetric®
Technology facilitates increased efficiency and
revenue by providing the versatility to safely lift
vehicles symmetrically or asymetrically within the
same service bay.
CL10V3 is an industry first two post lift with
standard Versymmetric® offset 3-stage front + 3-
stage rear arms. This arm configuration provides
maximum arm sweep, retration and reach , and
Info Requests
11´ 8˝ standard height allows lift to be placed in standard service bay with
12´ ceiling
Adjustable arm restraint shafts compensate for uneven floors
Grease fittings located on arm pin bushings minimize corrosion to keep arms
swinging freely
Available 2´ and 3´ column extensions enable technician to work at an
ergonomic height when servicing taller vehicles
Double Telescoping Screw Pads adjust to multiple heights minimizing the
need for adapters
48˝ elongated carriage design decreases load on bearing
Heavy-Duty 5˝ diameter pulley and 5/16˝ cable reduces stress on
equalization system and increases cable life
Padded overhead shut off system prevents vehicle damage
Single-point mechanical lock release system allows technician to disengage
both column locks simultaneously
Rubber door guards protect vehicles from door damage
Features & Benefits
single sweep spotting of virtually any vehicle. CL10 two post lift features
offset 2-stage front arms for a wide arm sweep with excellent arm retration
and reach.
Other CL10series two post lift features include double telescoping screw
pads, Heavy-Duty pulley and cable equalization system, elongated
carriage, fully gusseted base plate design, single point mechanical lock
release and padded overhead shut off system.
Model# CL10V3
Versymmetric® Plus 2-Post
Lift, 3-stage front and rear
arms 10,000 lb capacity
